MITSUBISHI HC-SF352B-S1 AC SERVO MOTOR HC-SF352B-S1
$2364.00
Shipped within 10-15 days and arrives at its destination.
Original, new, and high-quality product for industrial use.
For other product types, please send a quote to our email.
The Mitsubishi HC-SF352B-S1 is a medium-inertia, medium-power AC servo motor from the MELSERVO-J2S series. It is designed for high-precision industrial automation, featuring a built-in electromagnetic brake and an oil seal. Key Specifications (HC-SF352B-S1)
Rated Output Power: 3.5 kW (3500 W)
Rated Torque: 16.7 Nm (Nominal), 50.1 Nm (Maximum)
Rated Rotational Speed: 2000 RPM
Maximum Rotational Speed: 2500 RPM
Input Voltage: 200V AC Class (approx. 146V AC input dependent on drive)
Rated Current: 17 A
Encoder Resolution: 17-bit (131,072 pulses per revolution) absolute encoder
Shaft Type: Keyway shaft
Brake: Built-in electromagnetic brake
Protection Rating: IP65
