COPAL J50S-1K/2K/5K/10K J40S-1K/2K/5K/10K New Precision high life Potentiometer NIDEC COPAL
Rp4100000.00
Preorder 10-15hari sudah sampai di tempat
product original, new product dan berkualitas untuk Industri
untuk product type lain silahkan kirim penawaran ke email kami
COPAL J50S-2K potensiometer presisi dengan spesifikasi utama berupa resistansi nominal 2 kΩ, ukuran Ø 50.8 mm, dan tipe terminal solder turret. Potensiometer ini memiliki diameter poros 666 mm, sudut putar mekanik 360∘360 raised to the composed with power360∘ kontinu, dan sudut elektrik efektif 355∘±1.5∘355 raised to the composed with power plus or minus 1.5 raised to the composed with power355∘±1.5∘. Tipe aktunya adalah bulat dengan panjang 20.0020.0020.00 mm dan diameter 6.006.006.00 mm.
Spesifikasi utama
Resistansi Nominal: 222 kΩ
Ukuran: Ø 50.850.850.8 mm
Tipe Terminal: Solder Turret
Diameter Poros: 666 mm
Tipe Aktuator: Bulat
Panjang Aktuator: 0.7870.7870.787 inci (20.0020.0020.00 mm)
Diameter Aktuator: 0.2360.2360.236 inci (6.006.006.00 mm)
Sudut Putar Mekanik: 360∘360 raised to the composed with power360∘ kontinu
Sudut Elektrik Efektif: 355∘±1.5∘355 raised to the composed with power plus or minus 1.5 raised to the composed with power355∘±1.5∘
Spesifikasi lainnya
Daya Terukur (pada 40∘40 raised to the composed with power40∘ C): 1.51.51.5 W
Tahan Tegangan: 100010001000 Vrms selama 111 menit
Resistansi Insulasi Minimum: 100010001000 MΩ (pada DC500cap D cap C 500500 V)
Torsi Rotasi Maksimum: 0.690.690.69 mN.m, 777 gf.cm
Tingkat Kebisingan Puncak Maksimum: 101010 Ω (444 min-1)
Koefisien Suhu Resistansi: ±50plus or minus 50±50 ppm/$^\circ$C
Rentang Suhu Operasi: -55∘negative 55 raised to the composed with power−55∘ C hingga 85∘85 raised to the composed with power85∘ C
Kecepatan Rotasi Maksimum: 200200200 min-1
Akurasi Koneksi: ±1∘plus or minus 1 raised to the composed with power±1∘ berdasarkan terminal no. 111
Tingkat Proteksi: IP-40
