1734-AENT Allen Bradley Point I/O Ethernet/IP Adapter ANTR CAT1734-AENT
$965.00
Shipped within 10-15 days to reach its destination.
Original, new, and high-quality product for industrial use.
For other models, please send a quote to our email.
The Allen-Bradley 1734-AENT POINT I/O EtherNet/IP communication adapter module is designed to connect I/O modules to an Ethernet/IP network with 24V DC power. This module supports star or tree topologies, operates in a temperature range of -20°C to 55°C, and has one RJ45 Ethernet port. The following are the main technical specifications of the 1734-AENT.
Product Type: POINT I/O Ethernet/IP Adapter Module
Network Protocol: Ethernet/IP
Network Port: 1 x RJ45 (Category 5)
Input Voltage: 24V DC (nominal)
POINT Bus Current: 1000 mA maximum at 5V DC
Power Consumption: 4.5 W maximum at 28.8V DC
Power Dissipation: 15.5 BTU/hour maximum
Isolation Voltage: 50V (continuous), reinforced insulation type
Operating Temperature: (-20) to (+55) °C (-4) to (+131) °F)
